FEATURES

Compliance Standard:
Conforms to BS EN10219 TYPE 3 ,BS EN 39, or AS1163
& MS 1462-2-1 :2010 PPS CIDB Requirement
Mill Cert: Provided
Embossed: Brand Standard,Batch No/Year, Standard & Licence No Every 1.0 Meter Length On Tubes
Packing option:
61pcs or 37pcs ( Steel Strapped & unloading webbing sling provided)
Special Service:
i. can be cut to the required size upon request
ii. Customer name can be embbosed (T&C apply)

SPECIFICATION

Weight: 3.56kg/m
Length: up to 6.4m (21ft’) available in cut length
Diameter: 48.3mm,
Material: Hot Dipped Galvanised Steel -EN 10240
Type: 4
Grade: S355
Material Zinc Content: above 40 Micron

ENQUIRY

Select the quantity of product you require and click “Add to Quote” button at the bottom.”View Cart” link will appear for you to see the quote for your selected products and quantity. You can make changes to the quantity and products of your selection before sending your enquiry.

QtyProductCodeWeightRemarks
x KR-TUBES3-64 Steel Tube 6.4m x OD 48.3mm x 4.0mm 22.78
x KR-TUBES3-60 Steel Tube 6.0m x OD 48.3mm x 4.0mm 21.36
x KR-TUBES3-50 Steel Tube 5.0m x OD 48.3mm x 4.0mm 17.80
x KR-TUBES3-40 Steel Tube 4.0m x OD 48.3mm x 4.0mm 14.24
x KR-TUBES3-30 Steel Tube 3.0m x OD 48.3mm x 4.0mm 10.68
x KR-TUBES3-20 Steel Tube 2.0m x OD 48.3mm x 4.0mm 7.12
x KR-TUBES3-15 Steel Tube 1.5m x OD 48.3mm x 4.0mm 5.34
x KR-TUBES3-10 Steel Tube 1.0m x OD 48.3mm x 4.0mm 3.56
x KR-TUBES3-05 Steel Tube 0.5m x OD 48.3mm x 4.0mm 1.78
